Alignment in three axes, held by one clamp

The best telescope phone adapters for 2026

A phone held to an eyepiece will photograph the Moon, and everyone discovers that within a week of buying a telescope. What they also discover is that holding it steady while pressing a button is nearly impossible, and that the phone camera has to be centered on the eyepiece within a fraction of a millimeter or the frame goes black at the edges. A phone adapter exists to hold that alignment, and the ones that do it well share a property the photographs rarely show: adjustment in three axes, so that the camera can be moved across, along and away from the eyepiece independently. An adapter with a single clamp and no fine adjustment turns the problem into a wrestling match in the dark. Two dimensions decide compatibility. The eyepiece diameter range the collar accepts has to cover the eyepiece actually used — a wide-field two-inch eyepiece has a barrel far larger than a small one — and the phone width range has to cover the phone with its case on, or the case comes off every session. The other quiet specification is the camera offset: phones with camera modules near the corner need more travel than those with a centered lens, and some adapters cannot reach. Read the rigidity, because a plastic arm that flexes loses the alignment it took five minutes to find. We compare eyepiece diameter range, phone width range, three-axis adjustment, camera offset travel, clamp rigidity and case clearance.

By

The parts here, column by column

  1. SVBONY universal phone adapter in aluminum with a black clamp and EVA pads

    SVBONY Universal phone adapter (SW2546A)

    SVBONY's universal phone adapter: an aluminum-shell mount for eyepieces of 25 to 48 mm with a phone clamp from 52 to 100 mm that locks with a steel bolt instead of a spring, on EVA pads.

    Eyepiece diameter range
    25 to 48 mm (0.98 to 1.89 in) outer diameter · not 2 in eyepieces
    Phone width range
    52 to 100 mm (2.05 to 3.94 in)
    Three-axis adjustment
    Not described · up-down positioning for photos and sideways for video, stated
    Camera offset travel
    Not published by the maker.
    Clamp rigidity
    High-strength PA plastic clamp with an adjustable steel-bolt lock, not a spring · EVA pads
    Case clearance
    Not published by the maker.
    Amazon reference
    B01K7M0JEM
    EAN
    0608560886869
    • Wide phone range: 52 to 100 mm
    • Steel-bolt lock holds firmly
    • Phone compatibility list is years out of date

    Best for: A large current phone on a 1.25 in eyepiece, where the clamp has to hold rather than spring

    ≈ $11
    Check price on Amazon
